PAPER CURL, DIMENSIONAL STABILITY,
EFFECTS OF SHRINKAGE AND XEROGRAPHIC PAPER

(Note: this website can be reached via www.PaperCurl.com)

The information on this website is of a technical nature intended for people in the paper making related industries. Often what you are looking for can be more easily obtained with a direct inquiry by using the form at the bottom of the page.

When requesting articles through the website, be sure an email address is entered and is correct. Without an email address, requested articles cannot be delivered. Please email if requested articles are not received.

You can enter comments, below...

CURL BASICS (Read more in article Curl Basics, below )

Curl is effect of differential dimensional changes between layers in a sheet.
These are produced by different moisture expansions (usually from differences in fiber orientation); the release of differing amounts of internal strain; or from bending.
Xerographic (copier) curl is usually toward the print at moistures below 5-5.5% and away from the print at higher moistures for 75gsm papers.
Balancing amount of hydrophilic binder applied to each surface should reduce curl.
Adjustment of jet versus wire speed can reduce the difference in wire versus felt side fiber orientation.
A reduction in inherent moisture expansion of furnish should be helpful in reducing curl (see below).

DIMENSIONAL STABILITY (Read more in article Aspects of Dimensional Stability, below)

Inherent dimensional stability of a furnish or pulp needs to be measured on free dried sheets. If they are oriented sheets, a calculation of geometric mean expansion should be compared.
Factors in stability include fibril angle and degree of refining, additives, and filler.
Paper machine factors include fiber orientation, wet pressing, wet straining and sheet shrinkage.

SHEET SHRINKAGE IN DRYING

Shrinkage is perhaps the most important process effect on the mechanical properties of paper. Recently, Wahlstrom and Fellers showed that tensile stiffness, tensile strength, compressive strength and breaking strain are very closely correlate with sheet shrinkage or wet straining. A most likely explanation is that shrinkage affects micro-compressions, which in turn affects fiber properties, which affect sheet properties. Read more at "Effects of Paper Shrinkage" and "Property Relationships", below.

XEROGRAPHIC (copy) PAPER

Paper qualities important in xerographic papers include stiffness, smoothness, electrical resistivity, friction coefficient, curl, moisture, sheet flatness, millwork, porosity and composition. The usual basis weight of xerographic paper is 20 pounds (17" x 22" 500 sheets) or 75 grams/sq. meter. Good manufacturing control should keep weight within 0.5-0.75 pounds of nominal 99% of the time. The choice of a caliper specification depends on factors such as the type of fuser roll used in the copy machine. There may be no single set of paper properties that are optimum for all xerographic machines (including ‘laser’ printers). Read more at Summary of Xerographic Paper Properties, below.

Click here if you are having Problems With Paper Curl in a Printer or Copier.

Available electronic articles:

Click below to see descriptions and get access to any of the following articles:

$ArticleTable_Item[1] ($ArticleTable_Item[4], $ArticleTable_Item[2] pages)"; } } ?>

Click here to see descriptions and get articles emailed to you.

ASK THE CONSULTANT

For questions about paper curl, dimensional stability, copy paper or other paper properties use the form at the bottom of the page!

JOIN OUR INFORMAL E-MAIL NETWORK!

A number of us have joined together to form the CURL AND PAPER PHYSICS NETWORK (CPPN). By adding your email address to the list of participants you get periodic updates on new articles added to the library. Please use the form at the bottom of the page to get our updates. Your email request be acknowledged.

Charles (Chuck) Green, retired
Publisher, CPPN Electronic Library
Consulting: Curl, Xerographic Paper, Paper Physics
23 Maryvale Drive, Webster, NY 14580
585-265-9734

http://www.PaperCurl.com
